B&JMD812


Ball & Jewell Granulator Screen

Model: MD812


• Made from highest quality US Steel: Mild, Stainless and Plate

• Manufactured to exceed OEM specifications

• Custom screen hole shapes are available in: Circles, Squares, Hexagons and Octagons

• Screen hole sizes are available: 3/32 inch through 3 inches

• Metric hole sizes also available in millimeters or centimeters







Ball & Jewell Granulator Replacement Screens

These are the standard hole sizes however we custom manufacture these screens any hole size into any screens, within reason.

Part #: B&JMD812-332-J            Holes: 3/32 inch

Part #: B&JMD812-18-J              Holes: 1/8 inch

Part #: B&JMD812-532-J            Holes: 5/32 inch

Part #: B&JMD812-316-J            Holes: 3/16 inch

Part #: B&JMD812-732-J            Holes: 7/32 inch

Part #: B&JMD812-14-J              Holes: 1/4 inch

Part #: B&JMD812-516-J            Holes: 5/16 inch

These are the standard hole sizes however we custom manufacture these screens any hole size into any screens, within reason.

Granulator Screen Size

Part Length: 12.030 inches

Part Width: 8.190 inches

Part Thickness: 0.188 inches

Arc Depth: 1.900 inches
